The characteristics and use of waterproof plugs
Electricity is used a lot in our lives, whether it is indoors or outdoors, electricity is used. When we use electricity outdoors, we should pay special attention to waterproofing. When we buy it, we also need to pay attention to its waterproofness. Now there are many outdoor waterproof plugs on the market. When we need to choose a suitable one When using an outdoor waterproof plug, we need to understand its characteristics and how to use it. Choosing the correct waterproof plug will make our lives more convenient. Let's briefly introduce some outdoor waterproof plugs.
3 major features of outdoor waterproof plugs
1. Shell: The shells of waterproof plugs and sockets are made of imported high-quality plastic (nylon), which can reach 90°C without deformation under normal use, and the technical indicators of -40°C do not change.
2. Plastic core parts: the core parts of the waterproof plug and socket series products are all made of fireproof plastic (nylon) materials. It can withstand temperature of 120℃ under normal working environment. In the flame retardant test (850°C glow wire), there is no visible flame, no continuous glow, and the silk paper does not fire. The flame goes out within 30 seconds after the glow wire is removed, and the glow disappears.
3. Pins and sleeves: high-quality imported copper materials are used, with good plug-in function and anti-corrosion function. Both overcurrent and withstand voltage have reached the national advanced level.
How to use outdoor waterproof plug
1. Install the socket as far as possible in a hidden place out of rain.
2. It is necessary to choose a good-quality large-brand waterproof socket. The quality of the waterproof socket is not good. The safety hazard is relatively large when used in outdoor wet weather.
3. Cut off the outdoor power supply as much as possible on rainy days to avoid other accidents, and try not to be close to places with electricity as much as possible.
4. Outdoor sockets involve waterproof, dustproof, anti-aging, etc., so professional waterproof sockets must be used.
5. The protection level of outdoor plugs and sockets is relatively high. It is recommended to choose IP55 or higher.
There are many brands and types of waterproof plugs on the market, including traditional waterproof plugs used in home life, such as triangular plugs, etc., which can be called plugs, but they are generally not waterproof. So how is the waterproof plug determined? The waterproof measurement is IP, and the highest waterproof level is IP68. There are many domestic manufacturers of waterproof plugs.
The main assessment standard for the waterproof performance of waterproof connectors is based on the ip waterproof grade standard. Look at the waterproof performance of the waterproof connector, mainly look at the two digits XX at the back of IPXX, the first X is from 0 to 6, the highest level is 6; the second digit is from 0 to 8, the highest level is 8; therefore, the waterproof The highest waterproof rating of the connector is IP68.
Sealing principle: Rely on up to 5 sealing rings and sealing rings to pre-tighten the seal with pressure. This kind of seal will not lose the pre-tightening force when the connector heats up and shrinks, and the waterproof effect is guaranteed for a long time, and water molecules cannot penetrate under ordinary pressure.
After a brief introduction of the above content, I believe that everyone should have a more detailed understanding of the characteristics and usage of outdoor waterproof plugs. There are many types of outdoor waterproof plugs on the market, which generally belong to different brands. Under normal circumstances, the brand is good. The quality is better and the safety of use is higher, it has good practicability, and has a certain degree of waterproofness, which can meet the needs of daily life. Of course, when choosing, you should choose the corresponding power plug according to the different use occasions. Hope the above content is helpful to everyone.
