■Thread spec: PG
■Material: Parts A. C,E are made of UL approved nyon PA66.parts B and D are made of ntile butadiene rubber (INBR).
■Working temperature:-40℃ to 100℃ in static state, instantaneous heat resistance up to 120℃;-20℃ to 80℃in aynamic state, instantaneous
heat resistance up to 100℃.
■Characteristics: Speclal design of clamping die and rubber part. large range in clamping cable,ultra-strong stretching resistance, waterproof,
dustproof, and high ability to resist salt, acid, alkal, alcchol, grease and general solvent.
Schematic
technical parameter
